제품 세부 정보

집 상품

More choice for the style and sizes the single wall heat shrink tubing , 5%-8% lower than competitors' price

브랜드 이름:	none
모델 번호:	14mm-40mm
모크:	200
가격:	0.005
지불 조건:	TT in advance
공급 능력:	100000m/day

자세한 정보

제품 설명

자세한 정보

Place of Origin:

China

인증:

ISO9001

인장강도:

10.4Mpa

제품명:

단일 벽 열 수축 튜브

유전 강도:

600V/mm-1000V/mm

용법:

전기 절연

연장:

400%

크기 범위:

1.5MM~50MM

길이:

100M

색상:

주황색

포장 세부 사항:

판지로 밀봉된 플라스틱

Supply Ability:

100000m/day

강조하다:

single wall heat shrink tubing 80 Celsius

heat shrink tubing for wire harness

flexible insulating sleeve electrical protection

제품 설명

Product Description:

Our single-wall heat shrink sleeves are engineered to deliver reliable wire insulation and bundling, with a simple yet efficient working principle. Made of cross-linked polyolefin, they feature a memory effect—when heated to 90-110℃, their molecular structure rearranges, causing the sleeve to shrink radially (2:1 or 3:1 shrink ratio) and tightly wrap around wires, creating a secure protective layer that isolates conductors and prevents short circuits.

Equipped with outstanding core performance, our sleeves meet strict industry standards. They boast a wide operating temperature range of -40℃ to 125℃, adapting to harsh environments from cold warehouses to warm engine bays. The insulation strength reaches ≥15kV/mm, while flame retardancy complies with UL 94 V-0, ensuring self-extinguishing without toxic fumes. With a tensile strength of ≥10MPa and excellent wear resistance, they resist mechanical damage and prolong wire service life.

These sleeves excel in diverse scenarios. They are ideal for internal wiring of home appliances (air conditioners, washing machines) and consumer electronics (smartphones, laptops) for insulation and color-coded identification. In automotive interiors, they protect non-watery wiring like seat adjustment and door control lines. They also secure joints in indoor distribution cabinets and industrial control panels, simplifying maintenance.

Compared to competitors, our sleeves offer superior quality with stricter thickness uniformity and stable shrinkage. We balance performance and cost, providing 5-8% lower prices for equivalent specs. To ensure a perfect fit, we offer free sample delivery—just share your wire diameter and application needs, and we’ll tailor sample options for you. Trust our single-wall sleeves for cost-effective, reliable wire protection.

Product Name: Single Wall Heat Shrink Tubing
High elongation up to 400% for excellent flexibility
Available in vibrant orange color for easy identification
Comes in convenient spool packaging for efficient usage
Size range from 1.5mm to 50mm to suit various applications
Manufactured as thin wall single wall shrink tubing for lightweight protection
Compatible with 3m heat shrink tubing standards ensuring quality and durability

Technical Parameters:

Flammability	UL224 VW-1
Size Range	1.5mm To 50mm
Dielectric Strength	600V/mm - 1000V/mm
Material	Polyolefin
Color	Orange
Minimum Shrink Temperature	80°C
Packaging	Spool
Shrink Ratio	2:1
Tensile Strength	10.4MPa
Length	100m

Applications:

Single-wall heat shrink sleeves, characterized by their cost-effectiveness, basic insulation, and easy installation, serve as essential wire protection components across multiple industries. Their core value lies in providing reliable insulation, wire bundling, and identification while adapting to diverse working environments, making them indispensable in both civilian and industrial scenarios.

In the consumer electronics and home appliance industry, these sleeves are widely applied to internal wiring of devices like smartphones, laptops, air conditioners, and washing machines. They insulate small wire joints in circuit boards and control panels, preventing short circuits caused by contact between adjacent wires. Available in various colors (red, blue, yellow, etc.), they also facilitate wire identification, simplifying maintenance and repair work for technicians. Their thin wall and flexibility ensure they fit into compact device interiors without occupying excessive space.

The automotive and transportation sector leverages single-wall sleeves for non-watery areas inside vehicles, such as door control modules, seat adjustment wiring, and in-car entertainment systems. Made of wear-resistant materials, they resist friction from vehicle vibrations and protect wires from minor mechanical damage. For low-voltage automotive circuits, they meet basic insulation requirements while maintaining cost advantages compared to double-wall alternatives.

In industrial and electrical distribution, these sleeves play a key role in indoor power distribution cabinets, distribution boxes, and industrial control cabinets. They insulate branch wire joints, bundle messy cables, and enhance the overall neatness of electrical systems. For low-voltage industrial motors and weak current systems (network cables, telephone lines), they provide effective protection against dust and accidental contact, ensuring stable operation of equipment.

Additionally, they find uses in medical devices and small electronic components. Environmentally friendly variants (compliant with RoHS and REACH) are used in children’s electronic products and medical equipment, as they contain no harmful halogens or heavy metals. For sensors, connectors, and small terminal blocks, their tight fit after shrinking ensures long-term insulation reliability, extending the service life of precision components.
